Integrated toolkits accelerate CAE product development at every stage
PORTLAND, Ore., Sept. 28, 2022 /PRNewswire/ — Tech Soft 3D, the leading provider of engineering software development toolkits , today announces a new line of toolkits designed to fully support computer aided engineering (CAE) workflows. Comprising four components, the CEETRON suite of solutions enables software engineers to accelerate CAE application development at every stage of the process. The new toolkits bring together technology from Ceetron AS, Visual Kinematics (VKI) and Tech Soft 3D to provide the industry’s first complete platform for pre-processing, solving, and post-processing of CAE data, giving customers such as ANSYS, Elise GmBH, DNV, SimScale and nTopology one strategic partner to work with for their CAE applications.
“Bringing together the technologies acquired in 2020 to create a complete suite of CAE toolkits that connects with HOOPS and Polygonica is not only very exciting for us, but is also in line with our mission to empower our customers to create the most sophisticated applications and products using powerful, integrated and easy- to- use component technologies,” said Ron Fritz, CEO of Tech Soft 3D. “It has been especially rewarding to see the results of our successful acquisitions, not only from a product standpoint, but also to see our teams so well integrated and working towards the same goal. This is a milestone for our company, and we anticipate that our customers will be very happy with these new tools and the ability to relate to a single partner for all their CAE technology needs.”CAE Workflows are Unique
Throughout a typical CAE workflow, each step requires specific technologies, where the use of market-hardened toolkits is highly beneficial. When looking at the setup stage, HOOPS Exchange is the market’s best-in-class data access component, capable of bringing into play geometry from 30+ CAD formats. In many cases, the design needs healing prior to meshing: Polygonica is the ideal component to prepare tessellations for CAE. The CEETRON toolkit line takes the relay at that point, with CEETRON Mesh yielding both 2D and 3D meshes adapted to simulation purposes. When it comes to the calculations themselves, the CEETRON Solve SDK is an extensive framework to formulate finite element equations, assemble them into a global system, and eventually solve them through high-performance parallel (SMP) linear algebra.
The workflow ends with the analysis and sharing of the solver’s results analyzed by the expert eye of an engineer. With CEETRON Envision, Tech Soft 3D provides a palette of technologies to handle data extraction, display model generation, optimized rendering on desktop and native web, as well as data sharing and reporting.
Finally, the CAE workflow is also supported by general purpose technologies such as visualization, interoperability and automation. The new CEETRON Toolkits provide off-the-shelf solutions for each of these to help CAE developers reduce their development and workflow building efforts.
Few SDKs are as friendly as the CEETRON Toolkits and provide such a high level of development efficiency. With the same lines of code, developers can achieve reading capability of 30+ industry standard CAE formats and are able to write out 10+ formats to convey results to other packages. Last but not least, the toolkits are developed and supported by a highly responsive team of experienced developers.
“TRANSVALOR has a successful 25 year-long relationship with Ceetron, and this strategic partnership contributes efficiently to the solutions that TRANSVALOR develops for its customers,” said Stephane Heitz, CEO at TRANSVALOR. “It has been a key element in our historic leadership in material forming simulation software worldwide. We are looking forward to exploring the new possibilities now that Ceetron is a Tech Soft 3D company, and that the component offering covers the full simulation and analysis workflow. “Ceetron Envision
Ceetron Envision is the industry’s first all-in-one CAE analysis and visualization platform that provides a complete framework specialized in CAE data analysis and visualization. It includes data processing, rendering, automation and sharing, and is available for both browser-based web applications and more classical desktop ones. Envision allows developers to seamlessly dig into the large CAE datasets produced by solvers and provide interactive and automated analysis tools for expert engineering. Mechanical engineers can also share their analysis work through a wide variety of visualization outputs: HTML files, AR/VR headsets, Microsoft documents, interactive PPTs, etc. .
